Standard Resistance Range

1K,2K,5K,10K(Ω)

Special Practical Resistance Values

20K,50K,100K(Ω)

Total Resistance Tolerance

Standard Class ±15%(L), Precision Class ±10%(K)

Conformity Tolerance (Peak-Peak)

Standard Class ±0.5%, Precision Class ±0.3%, Super Precision Class ±0.2%

Resolution

Essentially infinite

Output Smoothness

<against input voltage 0.1%

Contact Resistance

<8%C.R.V.

Power Rating

1.25W

Electrical Travel

360°(Endless)

Mechanical Travel

360°(Endless)

Insulation Resistance

>1000MΩ(1000V.D.C.)

Dielectric Strength

1 minute at 1,000V.A.C.

Starting Torque

<5mN·m(50gf·cm)

Resistance Temperature Coefficient

±400p.p.m./℃

Mass

Approx.120g

Special shaft type

Shaft dia. (φ 6.35mm) with inch dimension, shaft with front and rear extension (Rear shaft with 6mm dia. and 15mm length), special machining on the shaft

Special mounting

Bushingmount type

Special gangs

Multi-ganged (Available up to 3 gangs. Housing length is extended by 17mm per 1 gang)
