Sibo занимается потенциометрами и датчиками уже 30 лет.

WLH22D
WLH22D

WLH22D

1-turn Contactless Magnetic POT.

瀏覽量： Вернуться: 2023-01-09

    Характеристики：

  • Magnetic rotary sensor

  • Low cost version

  • Plastic housing case

  • Bushing mount

  • Solder pads

Измерение


Параметр

General Mechanical Specifications

Mechanical angle

360º(Endless)

Mass

Approx.12g

Protection degree

IP40

Operating torque

<5mN·m

Max.mechanical speed

1500rpm

Life expectancy

50,000,000

Housing material

Plastic

Shaft material

Stainless steel

Environmental Specifications

Operating temperature range

-30℃～+85℃

Storage temperature range

-30℃～+85℃

ESD durability

Contact discharge ±8KV，Aerial discharge ±15KV，EN61000-4-2:2009

EMS durability

10V/m (80MHz～1GHz，1KHz80% Amplitude modulation)，EN61000-4-3:2006+A1:2010

General Electrical Specifications

Standard model

WLH22D 0505 W360

Input voltage

5V±10%

Output signal

0～100%Vcc

Current consumption (no-load)

<16mA

Output deviation at both ends

<1%·VCC

Load resistance

>100KΩ

Effective electrical angle

360º

Independent linearity tolerance

±0.5%

Resolution

4096 (12 Bit)

Update rate

0.3ms

Special Specifications Available

Special shaft

Special length of shaft、special diameter or special machining on shaft (like shaft slotted、fatted etc.)

Special torque

Products available for high torque <10mN·m.
